Modelo 60754WD
Diagrama Forward Reverse Shifting Sub Assembly
| 1 | 006512664U1 | RAIL FORWARD REVERSE |
| 2 | 006512846U1 | CAM SHAFT FORWARD REVERSE |
| 3 | 006512845U1 | CAM INNER FORWARD REVERSE |
| 4 | 006515073U1 | CLUTCH Housing |
| 5 | E007702564C91 | HEAD LAMP RH |
| 6 | 001082228R92 | OIL SEAL (PTO SHIFTER) |
| 7 | 000016322P04 | PLATE Locking 4WD |
| 8 | 006509853U1 | SPRING |
| 9 | 000020308E05 | BOLT M8 x 16 |
| 10 | 006503662C1 | BALL Poppet |
| 11 | 000016321P04 | WASHER Sealing Drop Box |
| 12 | 006511266U1 | COMPOUND ROLL PIN DIA 8 X 35 |
| 13 | 006513820V1 | BOLT SPRING RETENTION |
| 14 | 006512663U1 | FORK FORWARD REVERSE |
| 15 | 000012488P04 | WASHER Copper dia. 16 |
