Modelo 60754WD
Diagrama ECU and Horn Assembly
| 1 | 007701776C93 | CONTROLLER KKFM |
| 1 | 000020324E05 | BOLT M10 x 16 Bracket Water Separator Mounting |
| 1 | 007705508U91 | CABLE Battery Negative |
| 2 | 000020797E05 | BOLT M6 |
| 2 | 005556674R2 | GUARD Starter Motor |
| 2 | E007701562D91 | CABLE - Battery +ve |
| 3 | 007705613C91 | ECU EGR |
| 3 | E007700868B92 | STARTER Motor |
| 3 | E007703136C91 | BATTERY 12V, 88 AH Maint Free |
| 4 | SF0401002 | WASHER Plain M5 x 10 x 1 |
| 4 | 007706100U1 | STICKER Heat Reflective |
| 5 | 000934871R1 | NUT M3 |
| 5 | 005557308R2 | NUT Domed |
| 5 | SF0207008 | SCREW PHCR M5 x 0.8 x 27 x 6.6 |
| 6 | 000020797E05 | BOLT M6 |
| 6 | 007706109U91 | BRACKET EGR ECU |
| 7 | 001233808R1 | WASHER Spring |
| 7 | 001233807R1 | NUT M6 x 1 Hex. |
| 8 | 007700750B91 | HORN LT |
| 8 | 007705608C91 | WIRING HARNESS Engine |
| 9 | 007705514U1 | BRACKET Horn Mounting |
| 9 | E007703364D1 | BRACKET Z Type |
| 10 | E007702629H1 | Bracket Wiring Harness for 7mm Diameter Clip |
| 11 | 007705521U91 | BRACKET Harness Angle |
| 12 | 0304DAU02031N | CLIP Hose |
| 13 | 007705631U1 | BRACKET Channel Engine Harness |
| 14 | 000013084P05 | RELAY For Starter Motor |
| * | 007705608C91 | WIRING HARNESS Engine |
| * | 007704565U91 | WIRING HARNESS Fender RH |
| * | 007705513U91 | HARNESS Headlamp Pigtail |
| * | 007705608C91 | WIRING HARNESS Engine |
| * | 007704378U91 | PIGTAIL Harness Intake Heater |
| * | 007705610C91 | WIRING HARNESS Fender LH |
| A | 007703325C91 | ALTERNATOR |
